FP2000 Series - 4" Inlet Master Stream Fire Nozzle

In StockThis product is available for quick shipment nationwide.
Model FP2000ACG
Submittal
Submittal FP500 and FP1000 Series Monitor Nozzle (pdf)
Model FP2000ACG

FP2000 Series - 4" Inlet Master Stream Fire Nozzle

Fire Pro® Master Stream fog/straight stream nozzles are forged from heavy aluminum or brass casting that withstands caustic or saltwater environments using deck pipes and station monitors. Precision machining ensures ease of operation when changing patterns at all pressure ranges. Patterns change from a straight stream with maximum effective reach to a full 180° fog curtain.

FP2000ACG is constructed of heavy aluminum and FP200BCG of red brass casting. Either nozzle has a rating of 1500, 1700, 2000, 2500 gallons (5678,6435, 7571, 9464 liters) per minute.

Downloads

Resource Type
Title
Description
File Size
Action
PDF icon
Submittals
PDF icon
Submittal FP500 and FP1000 Series Monitor Nozzle (pdf)
Master Stream Nozzles [FP500A | 2-1/2" Inlet 350/500 GPM; FP500B | 2-1/2" Inlet 350/*500 GPM; FP500ACG | 2-1/2" Inlet 500/700 GPM; FP500BCG | 2-1/2" Inlet *500/700 GPM; FP1000ACG | 2-1/2" Inlet 1000/1250 GPM; FP1000BCG | 2-1/2" Inlet 1000/1250 GPM; FP2000ACG | 4" Inlet 1500/1700/2000/2500 GPM; FP2000BCG | 4" Inlet 1500/1700/2000/2500 GPM]654 KB
PDF icon
Product Literature
PDF icon
Fire Pro Monitor - Nozzle Catalog
14 MB

Specifications

Nozzle TypeMaster Stream
Inlet Size/Connection4"
Flow Rate1500 GPM, 1700 GPM, 2000 GPM, 2500 GPM
PatternCombination fog and straight stream
Weight11 lbs (5 kg)
MaterialAluminum
FinishGray hard anodized
SeatDelrin
Flow SettingFactory preset
